6
3. Installation
3.1.1. Component List
Code Instrument Sensor Accessories Batteries Manual
LPV4000.97.0002
sensION ™+ MM 150
–– ––
✓✓
LPV4059.97.0002
sensION ™+ MM 150
LZW5059.97.0002
✓✓✓
LPV4048.97.0002
sensION ™+ MM 150
LZW5048.97.0002
✓
(1)
✓✓
3.1.2. Accessories
• Carrying case.
• Buffer solutions, 125 mL, pH 4.01,
pH 7.00 and pH 9.21 (25 °C).
Calibration tubes pH 4.01,
pH 7.00 and pH 9.21.
• Standard solutions, 125 mL, 147 µS/cm,
1413 µS/cm and 12.88 mS/cm (25 °C).
Calibration tubes, 147 µS/cm,
1413 µS/cm and 12.88 mS/cm.
• Two 90-mL bottles for sample and sensor cleaning.
(1) Also included:
• Redox standard solution, 125 mL, 220 mV
(25 °C).
• Tube for redox standard calibration 220 mV.
After removing the instrument, check each part for possible damage. All components on the attached list
must be present. If there are any missing or damaged parts, contact the manufacturer or distributor.
WARNING
Risk of falling. Measurements are made directly in situ with this instrument. To prevent the risk of
falling, ensure compliance with all local safety regulations on securing with ropes and on the use of
adequate protective clothing and footwear.
Risk of injury. Do not attach the measuring instrument to your body. The measuring sensor could be
accidentally caught in a motor or stirrer and could endanger the user through the connected sensor
cable.
3.1. Content of the
sensION ™+ MM 150
Fig. 1. Equipment composition
