12
Installation
3.2.3 Charging the rechargeable batteries
Note: The instrument must be switched off while charging so that the rechargeable batteries can be
charged.
Note: When using the instrument for the first time, charge for at least three hours. The rechargeable
batteries are fully charged when the LED on the charger is green.
1. Connect the charger to the power supply source and then connect to the instrument
(Figure 4). The rechargeable batteries are charged.
2. Once the rechargeable batteries are fully charged, disconnect the instrument from
the charger.
Figure 3 Replacing the adapter
1 Charger
1
3 Removing the adapter
2 Slide switch
1
The battery charger must agree with local and national safety regulations and may not be part of the shipment. If the charger
is not part of the shipment, charge the batteries with a charger available in your country. Make sure that the charger agrees
the battery specifications.
