OPERATION
TURNING ON AND OFF
Note: The pulley cover must be closed to operate the drill press.
17
DRILLING
1. Ensure the drill press is switched off and disconnected from the power
supply.
2. Loosen the jaws of the chuck with the chuck key by turning in an
an-clockwise direcon and insert the selected drill bit into the as far as it
will go.
3. Insert the chuck key into 1 of the 3 locang holes and ghten unl drill bit is
secure.
Select your drilling depth and secure the depth stop lock knob in posion.4.
Switch the drill press On by pressing the green(I)buon on the switch
(Fig.42-43).
Switch the drill press Off by pressing the red(O)buon on the switch.
Secure your workpiece to the table if possible,use a vice or clamps.
1.
2.
3.
5. Adjust the table to your desired posion.
6. Slowly rotate the feed wheel handles to bring the drill bit down towards the
table and into your workpiece. Aer drilling a hole, release the feed wheel
handles slowly to return the chuck to its original posion.
7. Connue the operaon unl the task is completed. When completed, switch
the drill press Off by pressing the red (O) buon on the switch.
MAINTENANCE
For maximum performance, it is essenal that the Drill Press is properly
maintained. Always inspect it before use. Any damage should be repaired,
and
faults recfied. Always remove the plug from the power supply before carrying
out any adjustment, servicing or maintenance.
Fig.42
Fig.43
