Hafco bd-325 - Product Overview: Pedestal Drill; Pedestal Drill Component Identification

PEDESTAL DRILL
① Pulley Cover ⑧ Table Holder ⑮
Depth Stop Lock
Knob
② Motor ⑨
Belt Tension
Lock knob
⑯ Table Lock
③ Switch ⑩
Column
Support
⑰
Table Adjustment
Handle
④ Chuck guard ⑪ Base ⑱ Rack Collar
⑤ Chuck ⑫ Main Housing ⑲ Rack
⑥
Feed
Handle
⑬ Column
⑦ Table ⑭ Bolts
