hager EGN100 User Manual

16
Repeatedly pulse the FCT key to select the function (1).
For EGN100:
Confi rm the transmitter confi guration by pulsing its cfg button.
Confi rm your selection by pressing the FCT key and
holding for at least 2 seconds.
3
5
4
(1) For more information on functions, scan the appropriate QR Code at the end of the manual for instructions on installing the device.
> 2 s
cfg

hager EGN100 Specifications

General

Type	Time switch
Product color	Gray
Wire size range	0.2 - 4 mm²
Built-in display	No
Housing material	Plastic
Number of modules	1
Protection features	Scratch resistant
Compatible load types	Single-phase AC motor
Connectivity technology	Wired
International Protection (IP) code	IP20
AC input voltage	230 V
AC voltage range	230 - 254 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 45 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	62.5 mm
Width	17.8 mm
