Haglof Digitech User Manual

Digitech ENU rev. Feb 2011
©Haglöf Sweden®AB Mantax Digitech - 21 -
The parameters are shown and can be changed as follows:
Choose RAND menu and tree species 1 to 4 with the L or R key. Press E. The D value for the current tree species
is now featured in the display. By giving a short press on the E key, you step forward to the K value. Another
short press and you return to the chosen tree species.
If a value needs to be changed, press the key for a short while and move the caliper jaw until desired value is
featured in the display. Tree species with a K-value 00 will not be marked as sample trees.
SET
One- or more key function is set in this menu, and Radio- or IR-transfer.First select between 1but (one-key
function) or 3but (3-key function). Use the arrow keys L and R to choose 1but or 3but, activate your choice with
the E-key.
1but Choose species and register diameter with the E-key.
3but Choose species with L and R keys and register diameter the E-key.
Then select Radio- or IR- transfer. This selection has to be made depending on what receiver you intend to use
when sending captured data.
Rdio: Radio transfer
Ir: Infra red transfer
