ASSEMBLE THE CALIPER JAWS
Assemble the caliper jaws using the enclosed Allen key (wrench) and the screws with washers.
Tighten the screws using the Allen key.
Make sure the jaws are correctly assembled and guided
into the material marks on your caliper.
Mount the jaw lids
4X
4X
1X
2X
4X
