SERVICE MANUAL
Model: AFL631 & CFE633
18
Issue 200905
Rev. Ref0905S003V0
Chapter 4 Control and display system
4-1. Control and display panel
4-1-1 Models: CFE633*
Control panel
Super cooling
button
Fridge storage
temperature setup
knob
Power
indicator
Freezer
storage
temperature
setup knob
Super
freezing
button
■ Initial powering on
Upon initial powering on, the power indicator will illuminate. There will be alarm due to high
temperature in the freezer storage compartment. You can cancel the alarm by pressing any key.
■ Fridge storage temperature setup
The temperature in the fridge storage compartment can be set by turning the fridge storage
temperature setup knob. There are three temperature positions for refrigerating: Holiday, Moderate
and Super Cool.
■ Freezer storage temperature setup
The temperature in the freezer storage compartment can be set by turning the freezer storage
temperature setup knob. There are three temperature positions for freezing: Weak, Moderate and
Super Freeze.
■ Super cooling
Select this function after you have put fresh food in the fridge storage compartment. Press the super
cooling button, the refrigerator activates this function and corresponding indicator illuminates. This
function will automatically deactivate when the temperature decreases to the required level. You can
also deactivate it by pressing the super cooling button again.
■ Super freezing
Select this function after you have put large amount of food in the freezer storage compartment. Press
the super freezing button, the refrigerator activates this function and corresponding indicator
illuminates. This function will become automatically deactivate after 24 hours. You can also deactivate
