SERVICE MANUAL
Model: AFL631 & CFE633
9
Issue 200905
Rev. Ref0905S003V0
2-3. External views
2-3-1 Three-Door Refrigerator Structure
Fridge storage compartment
Freezer Drawer Structure
Transparent tray
Bottom door drawer
Display panel
Crispe
r
Bottom door drawer
Middle door drawer
Small bottle rack
Large bottle rack
Middle bottle rack
Butter box
Turnover box rack
Turnover box (include egg box)
Fresh keeping box cove
r
Wire wine holde
r
Shel
f
Crisper cove
r
Fresh keeping box
Middle door drawer
