Installation
GB GB
Installation
Waiting time
To the maintenance-free lubrication oil is located in the
capsule of the compressor. This oil can get through
the closed pipe system during slanting transport. Be-
fore connecting the appliance to the power supply you
have to wait 2 hours so that the oil runs back into the
capsule.
2 h
Aigning the appliance
The appliance should be placed on a at and solid sur-
face.
1. Tilt the appliance slightly backwards.
2. Set the feet to the desired level.
Make sure the distance to the wall on the hinge side is
at least 100 mm for the door to open properly.
3. The stability can be checked by alternately bump-
ing on the diagonals. The slightly swaying should
be the same in both directions. Otherwise the
frame can warp; possible leaking door seals are
the result. A low tendency to the rear facilitates
the closing of the door.
max 45°
1. 2.
3.
WARNING!
To avoid risks a damaged power cord must be replaced by the customer service (see
warranty card).
Electrical connection
Before each connection check if:
power supply, socket and fusing are appropriate to the rating plate.
the power socket is earthed and no multi-plug or extension.
the power plug and socket are strictly according.
Connect the plug to a properly installed household socket.
Door Reversibility
(Only model A3FE742CMJ,C3FE744CMJ and C3FE744CWJ)
Before connecting the appliance to the power supply you should check, whether the door
swing must changed from right (as delivered) to left, if this is required by the installation
location and the usability.
WARNING!
The appliance is heavy. You need two persons to carry out the door reversibility.
Before any operation, rst unplug the appliance from the mains .
Do not tilt the appliance more than 45 ° to prevent damage of the cooling system.
1. Provide necessary tool.
2. Unplug the appliance.
3. Remove the xation of the cover
4. Remove the faceplate of the body
5. Remove the topplate of the upper door.
6. Remove the hinge cover.
7. Unplug the connection cable
8. Unscrew the upper hinge.
9. Lift the loose upper door carefully o the lower
hinge.
10. Turn the upper door upside down and change the
position of the hinge barrel on the lower side of
the door.
11. Change the door stop from the current position
to opposite side
12. Unscrew the lower hinge of the upper door.
1. 2.
3. 4.
5.
25
6.
7. 8.
9.
10.
12.
11.
30 31

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Haier C3FE744CMJ and is the answer not in the manual?

Haier C3FE744CMJ Specifications

General IconGeneral
Child lockNo
Door hingeRight
Control typeTouch
Product colorStainless steel
Built-in displayYes
Shelves materialGlass
Appliance placementFreestanding
Lamp typeLED
Fridge net capacity311 L
Fridge door balconies3
Number of vegetable drawers1
Star rating4*
Freezer positionBottom-placed
Freezing capacity12 kg/24h
Freezer net capacity148 L
Storage time during power failure16 h
Fresh zone compartment net capacity40 L
Current1.4 A
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Annual energy consumption285 kWh
Control positionInternal
Noise level37 dB
Climate classT
Total net capacity459 L
Package depth752 mm
Package width770 mm
Package height2000 mm
Package weight112000 g
Weight and Dimensions IconWeight and Dimensions
Depth676 mm
Width700 mm
Height1905 mm
Weight102000 g
