Anti-Flooding protection
The dishwasher is equipped with a system that stops the supply of water
in the event of a problem with the water supply hose, or leaks within the
unit, in order to prevent damage to your home. If for any reason the box
containing the electrical components happens to get damaged, turn off the
power supply and remove the plug for the appliance from the socket
immediately. In order to guarantee that the anti-floodin
g feature operates
properly, the “A” box with water supply hose must be attached to the water
supply tap as shown in fig.B. No other type of connection is acceptable.
The water supply hose must not, under any circumstances, be cut, as it
contains electrical parts which are live. If the length of the hose is not
adequate to make a proper connection, the hose must be replaced with
one which is long enough. This hose is availa
ble upon request from
specialised retailers and Authorised Service Center.
Drain Water Connection
Fix the water drain hose properly to
Following connections are possible:
Drain hose to sink
the piping.The hose has to reach at one
point a height between 400 and 850 mm
above the appliance bottom line!
An extension hose for the water drain
hose must not exceed a total length of 4
m and must have the same diameter as
the water drain hose.
Hang the drain hose with the
U-support over the edge of a sink
with adequate size.
Protect the U-support sufficiently
against slipping.
7
Installation
NZ AU
