Haier HW100-B14876 User Manual

EN
2-Product description
7
2.1 Picture of appliance
Front (Fig. 2-1): Rear side (Fig. 2-2):
2.2 Accessories
Check the accessories and literature in accordance with this list (Fig.:2-3):
Note:
-
2-3
Underwear
Sport
Anti-allergy
Daily Wash
Synthetic
Mix
Baby Care Hygienic
Self Clean
Spin/Drain
Express15 min
Duvet
Delicate
Wool
Temp. SpeedDelay Start/PauseExtra
Rinse
Cotton
Cotton+
HW80-B14876
Steam
8kg
I1
R5
R9 R10
R6
R7
R8
1 Detergent /
Softener drawer
2 Work top
3 Display
4 Programme selector
5 Panel
6 Service flap
7 Adjustable feet
8 Door handle
1 Iron bar (I1 - I2)
2 Transportation bolts (T1-T4)
3 Rear wall reinforcement
(HW80:1 pcs;HW100:2 pcs)
4 Power cord
5 Water inlet vave
6 Drain hose
7 Rear wall reinforcement screws
(HW80:4 pcs ,R1-R4;HW100:10 p cs ,R1-R10)
2-1
2-2
Inlet hose-
assembly
1)
6 Blanking
plugs
Drain hose
bracket
User manual
Warranty
card
1
6
8
7
3 5
1 2 4 5 6 73
42
Noise reduc-
tion pads
2x
2x

Haier HW100-B14876 Specifications

General

Door hinge	Left
Motor type	Beltless
Control type	Rotary, Touch
Loading type	Front-load
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Custom panel-ready	-
Appliance placement	Freestanding
Washing class	A
Annual water consumption washing	11400 L
Annual energy consumption washing	118 kWh
Drum capacity	10 kg
Cycle time (max)	270 min
Delay start (max)	24 h
Residual moisture	53 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	71 dB
Noise level (wash)	58 dB
Foam control system	No
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.45 W
Power consumption (left-on)	0.58 W
Energy consumption washing per cycle	0.5 kWh
Package weight	84000 g

Weight and Dimensions

Depth	530 mm
Width	595 mm
Height	850 mm
Weight	77000 g
