Haier HW100-B14979 User Manual

3-Control panel
EN
10
Delay
Extra Rinse
Fin différée
Rinçage + Essorage
Extra Rinse
3.5.4 Function button“Speed“
Touch this button (Fig. 3-10) to change or deselect the
spin of the programme. If no value is illuminated the
display (“”) laundry will not spin.
3.5.5 “Extra Rinse“ button
Touch this button (Fig. 3-11) to rinse the laundry more
intense with fresh water. This is recommended for
people with sensitive skin. By touching the button seve-
ral times one to three additional cycles can be selected.
They appear in the display with P--1/P--2/P--3.
3.6 “Start/Pause“ button
Press this button (Fig. 3-14) gently to start or inter-
rupt the currently displayed programme. During pro-
gramme setting and during programme run the LED
above the button is shining, or if interrupted blinking.
3.5.7 “Stain removal“ button
Press this button (Fig. 3-13) to choose special features
for stains. The symbols are explained in the following table
3.5.6 “Steam“ button
Touch this button (Fig. 3-12) the steam program can
be selected.For programs with the steam function,
the indicator is green, and the indicator in the middle
of the knob is on.You can select if you require this
funtion when programmes “Cotton,Synthetics, Mix,
Baby care,” are used.The steam wash icon will light up
when using the steam wash function.
3.7 Child lock
Choosing a program and then start,touch button“
Speed”and ”Start/Pause ”( Fig .3-15) for 3 seconds
simultaneously to block all panel elements against
activation,panel display .For unlocking please touch
again the two buttons.The child lock indicator lights
up when the child lock works. Feature is optional when
the machine is running
The display shows  (Fig. 3-16) if a button will be
pressed, when the child lock is activated. The change
is not running.
3-10
3-11
3-10
Essorage
3-12
Vapeur
3-13
Taches
3-14
Essorage
3-15
3-16
3-12
3-13
3-14
3-15
3-16
Grass
Soil
Wine
Blood
Milk
Juice

Haier HW100-B14979 Specifications

General

Door color	Black
Door hinge	Left
Motor type	Beltless
Water fill	Cold
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Custom panel-ready	-
Illumination color	Blue
Appliance placement	Freestanding
Drum capacity	10 kg
Cycle time (max)	238 min
Delay start (max)	24 h
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	69 dB
Noise level (wash)	- dB
Number of washing programs	14
Maximum washing temperature	90 °C
Power plug type	Type F (CEE 7/4)
AC input voltage	220 - 240 V
Energy efficiency scale	A to G
Power consumption (standby)	0.45 W
Water consumption per cycle	51 L
Energy consumption washing per cycle	0.512 kWh
Package depth	646 mm
Package width	653 mm
Package height	890 mm
Package weight	82000 g

Weight and Dimensions

Depth	620 mm
Width	590 mm
Height	850 mm
Weight	77000 g
