Haier HW120-B14979 Service Manual

8-4. Joining the Inlet Hose to the Washing Machine ____________________________
8-5. Drainage Hose _____________________________________________________
8-6. Connecting to the Power Supply _______________________________________
Chapter 9 Wiring circuit and Self check ______________________________________
9-1. Wiring circuit _______________________________________________________
9-2. Self check _________________________________________________________
Chapter 10 Error Display and troubleshooting _________________________________
10-1. Error Display ______________________________________________________
10-2. Examination & Troubleshooting _______________________________________
10-2-1. Display nothing _________________________________________________
10-2-2. No water inletting _______________________________________________
10-2-3. No draining ____________________________________________________
10-2-4. Abnormal noise and vibration ______________________________________
10-2-5. Water leaking __________________________________________________
Chapter 11 Disassembly guide ___________________________________________________
10-3. Parameter of primary eletronic appliance _______________________________
17
17
17
18
19
20
21
21
30
30
30
31
31
32
33
36
979
2

Haier HW120-B14979 Specifications

General

Door color	Black
Door hinge	Left
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Custom panel-ready	-
Appliance placement	Freestanding
Drum capacity	12 kg
Cycle time (max)	238 min
Delay start (max)	24 h
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	69 dB
Noise level (wash)	54 dB
Number of washing programs	14
Cycle time (quick washing program)	15 min
AC input voltage	220 - 240 V
Energy efficiency scale	A to G
Water consumption per cycle	56 L
Energy consumption washing per cycle	- kWh
Package depth	714 mm
Package width	653 mm
Package height	890 mm
Package weight	86000 g

Weight and Dimensions

Width	600 mm
Height	850 mm
Weight	80000 g
Door diameter	320 mm
