4-3-2-3.L42F6
CN3
CN4
CN3
Pin number
Signal name
Pin number
Signal name
1
2
3
4
9
10
11
12
5
8
GND
GND
GND
24V
24V
24V
24V
24V
6
7
13
14
GND
GND
DC-DIMMING
BL-ON/OFF
PWM-DIMMING
STATUS
CN4
Pin number
Signal name
Pin number
Signal name
1
2
3
4
11
12
13
14
5
10
24V
GND
GND
12V
P-ON/OFF
12V
24V
12V
6
7
15
16
GND
GND
DC-DIMMING
BL-ON/OFF
PWM-DIMMING
8
9
17
18
GND
GND
GND
5V
STATUS
Service Manual
Model No.:
/)
28
