LVDS:
Connector on Panel: 093G30-B0001A-1 (Manufactured by )
Pin No Symbol Description Default
1 VCC +12V, DC, Regulated
2 VCC +12V, DC, Regulated
3 VCC +12V, DC, Regulated
4 VCC +12V, DC, Regulated
5 GND Ground and Signal Return
6 GND Ground and Signal Return
7 GND Ground and Signal Return
8 GND Ground and Signal Return
9 LVDS Option Low/Open for Normal (NS), High for JEIDA NS mode
10 Reserved Open AUO internal test
11 GND Ground and Signal Return for LVDS
12 RIN0- LVDS Channel 0 negative
13 RIN0+ LVDS Channel 0 positive
14 GND Ground and Signal Return for LVDS
15 RIN1- LVDS Channel 1 negative
16 RIN1+ LVDS Channel 1 positive
17 GND Ground and Signal Return for LVDS
18 RIN2- LVDS Channel 2 negative
19 RIN2+ LVDS Channel 2 positive
20 GND Ground and Signal Return for LVDS
21 RCLK- LVDS Clock negative
22 RCLK+ LVDS Clock positive
23 GND Ground and Signal Return for LVDS
24 RIN3- LVDS Channel 3 negative
25 RIN3+ LVDS Channel 3 positive
26 GND Ground and Signal Return for LVDS
27 Reserved Open or High AUO internal test
28 Reserved Open or High AUO internal test
29 GND Ground and Signal Return
30 GND Ground and Signal Return
Service Manual
Model No.:
/)
32
