4-4-2-3.L42F6
AUO
˄
˅
NVERTER UNIT
Symbol Description
VDDB (Main Power) DV input 24.0 VDC
VDDB (Main Power) DV input 24.0 VDC
VDDB (Main Power) DV input 24.0 VDC
VDDB (Main Power) DV input 24.0 VDC
VDDB (Main Power) DV input 24.0 VDC
GND Ground
GND Ground
GND Ground
GND Ground
GND Ground
Reserved Please leave it open
VBLON (Enable Pin)
BL On/Off control signal
High/Open: On, Low: Off
(Low=0~ 0.8V, High=2.0~5.0V)
VDIM
Internal PWM (3.3V,100% duty)/open for 100% luminance,
0V : 10% duty
NC
I
7+:9
Service Manual
Model No.:
/)
33
