P-TWO 187059-5122 which is compatible FI-RE51S-HF (JAE)
Note: 1. All GND (ground) pin should be connected together to the LCD module’s metal frame.
2. All V
LCD
( power input ) pins should be connected.
No Symbol Description
No Symbol Description
1 GND Ground 27 GND Ground
2 NC No connection 28 RE0N SECOND CHANNEL 0-
3 NC No connection 29 RE0P SECOND CHANNEL 0+
4 NC No connection 30 RE1N SECOND CHANNEL 1-
5 NC No connection 31 RE1P SECOND CHANNEL 1+
6 Reserved 32 RE 2N SECOND CHANNEL 2-
7 LVDS SEL LVDS order 33 RE 2P SECOND CHANNEL 2+
8 NC No connection 34 GND Ground
9 Reserved 35 RECLKN SECOND CLOCK CHANNEL C-
10 Reserved 36 RECLKP SECOND CLOCK CHANNEL C+
11 GND Ground 37 GND Ground
12 RO 0N FIRST CHANNEL 0- 38 RE3N SECOND CHANNEL 3-
13 RO 0P FIRST CHANNEL 0+ 39 RE3P SECOND CHANNEL 3+
14 RO 1N FIRST CHANNEL 1- 40 NC No connection
15 RO 1P FIRST CHANNEL 1+ 41 NC No connection
16 RO 2N FIRST CHANNEL 2- 42 GND Ground
17 RO 2P FIRST CHANNEL 2+ 43 GND Ground
18 GND Ground 44 GND Ground
19 ROCLKN FIRST CLOCK CHANNEL C- 45 GND Ground
20 ROCLKP FIRST CLOCK CHANNEL C+ 46 GND Ground
21 GND Ground 47 NC No connection
22 RO 3N FIRST CHANNEL 3- 48 VLCD Power Supply +12V
23 RO 3P FIRST CHANNEL 3+ 49 VLCD Power Supply +12V
24 NC No connection 50 VLCD Power Supply +12V
25 NC No connection 51 VLCD Power Supply +12V
26 GND Ground - - -
Service Manual
Model No.:
/)
34
To Next Page
