Haier LE40K6500DA - Installation and Setup; 32-Inch Base Stand Assembly

32"BASE STAND ASSEMBLY
-5-
M4X12MM
Note: This stand is not a swivel stand. Do not attempt to rotate the TV.
2. Lock 4PCS screws below and check each screw is firmly tightened.
1. Place the TV with the display side down on a flat surface. Use a cloth to protect the
display.
Locate the 2PCS of bottom bracket into the gap in the bottom of the TV.
