WALL MOUNT INSTALLATION
-8-
wall
wall
Step One: Use the expansion bolts( ) to fix the wall mount brackets into the wall.4*36PWA
Step Two: Fix the wall mount screws into the
rear side of the LCD TV,using the tongue of
(32"M4x5mm/4pcs, 40"M6x8mm, 43"/49"M6x12mm)
8kgf.cm.
* The TV appearance subject to material object.
Step Three: Put the LCD TV with wall mount screws onto the wall mount brackets.
Warning: the angle between the TV and wall must not be bigger than 3º.
