Haier LTF42M1C - IR Board

65
10.5 IR Board
715G3733R0B000004S
C001
100pF/50V
Q003
MMBT3904
R011
12K 1/10W 5%
3.3V
I R
R010
680 OHM +-5% 1/10W
Q002
MMBT3906
3 . 3 V
R012 47K 1/10W 5%
R E D
R001
12K 1/10W 5%
R008
NC
R007
NC
3.3V
U001
KSM-2003TN2E
1
2
3
VOUT
GND
VCC
C002
10uF/10V
R013
10K 1/16W 5%
R004 100 OHM +-5% 1/10W
CN001
CONN
1
2
3
4
5
6
78
C003
0.1uF 50V
R002
47K 1/10W 5%
R009
680 OHM +-5% 1/10W
G R E E N
3.3V
3.3V
LED001
LED
3 4
1 2
R003 33 OHM +-5% 1/10W
R014 NC
3.3V
Q001
MMBT3906
R005
10KOHM +-5% 1/10W
