12. BOM List
Note: The parts information listed below are for reference only, and are subject to change without notice. Please go
to http://cs.tpv.com.cn/hello1.asp for the latest information.
LTF42M1C E429M2NBW9H72N
Location
Part No. Description Remark
052G 1150 C INSULATING TAPE
052G 1185 MIDDLE TAPE (Y1200141)
705TQ9SCN11 MAIN BOARD ASS'Y
0M1G 930 6 47 CR3 SCREW
0Q1G 930 8 47 CR3 SCREW
A15T0886102 BKT-IO-SIDE-TOP
CBPF92SBQ6S MAIN BOARD
017G MB519TSB 2 HAIER MAIN BOARD CBPF92SBQ6
TU201 094G DVB T 8P TUNER DVB-T WITH ANALOG FQD1116ME/BM 2nd source
Q40G000378643A SIDE LABEL
A15T0303103 FIX BKT FOR AUO SIDE
INTV8QGGMQA7 INVERTER BOARD
040G 45762412B CBPC LABEL
CN8802 033G8029 3A H B2P3S-VH
CN8810 033T8021 2A U CONN 13.0MM 2P R/A
CN8809 033T8021 2A U CONN 13.0MM 2P R/A
CN8808 033T8021 2A U CONN 13.0MM 2P R/A
CN8807 033T8021 2A U CONN 13.0MM 2P R/A
CN8806 033T8021 2A U CONN 13.0MM 2P R/A
CN8805 033T8021 2A U CONN 13.0MM 2P R/A
CN8804 033T8021 2A U CONN 13.0MM 2P R/A
CN8803 033T8021 2A U CONN 13.0MM 2P R/A
C8812 065G 6J3096ET CER CAP 3PF J 6KV
C8813 065G 6J3096ET CER CAP 3PF J 6KV
C8814 065G 6J3096ET CER CAP 3PF J 6KV
C8815 065G 6J3096ET CER CAP 3PF J 6KV
C8816 065G 6J3096ET CER CAP 3PF J 6KV
C8817 065G 6J3096ET CER CAP 3PF J 6KV
C8818 065G 6J3096ET CER CAP 3PF J 6KV
C8819 065G 6J3096ET CER CAP 3PF J 6KV
C8811 065G 6J3096ET CER CAP 3PF J 6KV
C8810 065G 6J3096ET CER CAP 3PF J 6KV
C8809 065G 6J3096ET CER CAP 3PF J 6KV
C8808 065G 6J3096ET CER CAP 3PF J 6KV
C8807 065G 6J3096ET CER CAP 3PF J 6KV
C8806 065G 6J3096ET CER CAP 3PF J 6KV
C8805 065G 6J3096ET CER CAP 3PF J 6KV
C8802 065G 6J3096ET CER CAP 3PF J 6KV
CN8801 095G 825 6D505 HARNESS 6P(SCN)-5P(PLUG) 230MM
CN8801 095G 825 6W505 HARNESS 6P(SCN)-5P(PLUG) 230MM 2nd source
R8822 061G0805000 RST CHIP MAX 0R05 1/8W
R8823 061G0805000 RST CHIP MAX 0R05 1/8W
R8824 061G0805000 RST CHIP MAX 0R05 1/8W
R8825 061G0805000 RST CHIP MAX 0R05 1/8W
R8826 061G0805000 RST CHIP MAX 0R05 1/8W
R8827 061G0805000 RST CHIP MAX 0R05 1/8W
R8828 061G0805000 RST CHIP MAX 0R05 1/8W
