- 65 -
0010451181A（CN10 terminal of EEV 6-core red）
SW07-7 ON J9
connected
SW07-8 ON J8
connected
change running mode that displayed
on wired controller
(J8)0(J9)0: AUTO/HEAT/
DEHUMIDIFY /COOL/SWING
(J8)0(J9)1: Auxiliary heat / HEAT
/DEHUMIDIFY /COOL/SWING
(J8)1(J9)0: DEHUMIDIFY
/COOL/SWING
(J8)1(J9)0: HEAT /DEHUMIDIFY
/COOL/SWING
SW08-1 ON J24
connected 0:when unit stops, oil return, in low
speed
1: fan stops
SW08-2 ON J23
connected 0: in heating mode, running as med
speed in high speed(only fo
3-speed fan motor)
1: normal
SW08-3 OFF J22
disconnecte
d
0: in heating, thermostat Off, and
adjust valve due to the coil temp. Tc2
and ambient temp.
1.adjust according of outdoor high
pressure saturation temp.
SW08-4 ON J21
connected 0：Ac stepless fan motor
1：AC fan motor with three speed
SW08-5 ON J20
connected
standby
SW08-6 ON J19 connected
0: remote controlled 1: wired
controlled
SW08-7 OFF J18
disconnecte
d
change phase sequence of EEV
0: reverse
1: forward
SW08-8 ON J17 connected
0: fixed swing
1: adjustable
remark: for digital dip switch, dial to “ON” means “1”, or it means “0”
