102
Smart Power
Item Model 1UH250W1ERK
Power cable H05RN-F 5G 6.0mm
2
Communication cable /
Connecting cable H05RN-F 4G2.5mm
2
Power source N, V, Hz 3N~,380~415, 50/60Hz
Start current A 3
Indoor unit
Unit model (color) 1UH250W1ERK(WHITE)
Compressor
Model / Manufacture/place LNB53FDAMC(MITSUBISHI ELECTRIC
COMPRESSOR CO.,LTD)
Oil model FV50S
Oil charging 1700CM
3
Type Twin rotary 1
Fan
Type × Number Axial×2
Speed r/min 780±50
Fan motor input power kW 0.19×2
Fan motor output power kW 0.145×2
Air-ow(H-M-L) m³/h 10400
Heat exchanger
Type / Diameter mm TP2M/Φ7.94
Row/Fin pitch 2 1.5
Total area m² 1.17
Dimension
External(W×D×H) mm×mm×mm 1050×400×1636
Package(W×D×H) mm×mm×mm 1150×510×1795
Drainage pipe (material, I.D./O.D.) mm None
Refrigerant control method mm/mm Electronic vave 3.2mm
Defrosting Auto
Volume of accumulator L 4.0
Sound power noise level (H-M-L) dB(A) 75
Sound pressure noise level (H-M-L) dB(A) 64
Type of four way valve SHF-35B-67-04
material of reduce noise XPE
crankcase heater power W 38
Weight(Net / Shipping) kg / kg 160/175
Piping
Refrigerant
Type / Charge g R410A/6350
Maximum pipe length without
recharge refrigerant
m 30
Recharge quantity g/m 90
Pipe
Liquid mm 12.7
Gas mm 22.22
Connecting method Welding
Between I.D
&O.D
MAX.Drop m 50
MAX.Piping length m 75
Tdesignh: -10°C Tbivalent: -10°C TOL:-15°C Elbu:0
Max. cooling condition
Indoor temperature:32°C/23°C
Max. heating
condition
Indoor temperature:27 °C/ -°C
Outdoor temperature:46°C/-°C Outdoor temperature:24°C/ 18°C
Norminal condition:
indoor temperature (cooling): 27°C DB/19°C
WB, indoor temperature (heating): 20°C DB
Outdoor temperature (cooling): 35°C DB/24°C WB, outdoor temperature (heating): 7°C DB/6°C WB
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated sound intensity meter. It is a
sound pressure noise level.
