4. Wiring Diagram
ADH071M1ERG ADH090M1ERG
2014.01.11
SW1-7
SW1-8
Type define
ON
OFF
Medium ESP DUCT
SW1-3
B:BLACK
R:RED
W:WHITE
Y/G:YELLOW/GREEN
ON OFF ON
OFF ON ON
7.1 9.0
NOTE: 1.DASHED PARTS ARE OPTIONAL. 2.
USER SHOULD NOT SET SW1
AND SW2 WITHOUT GUIDENCE. 3.THE BRIDGE (CN22 CN23) ON SLAVE UNITS PCB SHOULD BE CUT OFF WHEN ONE WIRED CONTROLLER CONTROL MORE THAN ONE UNIT. 4.REFER TO INSTALLATION MANULTO GET MUCH MORE DETAILS ABOUT THE STATIC PRESSURE LEVEL SELECTION.
OFF
OFF
SW1-4
SW1-5
SW1-6
OFF
Static pressure
OFF
OFF
ON
TEMP.
SENSOR
ROOM
SENSOR
PIPING TEMP.
ROOMCARD
CN13
CN19
CN14
CH3
CN29
R O T O M N A F C D
CN36
CN7
CN18
CN5
CN6
CN15
CN37
CN4
CH1
CH2
CN9
CN1
SW1
SW2
T5A/250VAC
FUSE
WIRED
CONTROLLER
FLOAT SWITCH
WIFI
CN8
CN22 CN23
PUMP
TO OUT DOOR
2
1
3
B
W
R
Y/G
ON
ON
ON
ON
4th level
1st level
Room card
M
87654321
4321
ON
ON
REMOTE RECEIVER
M
B
A
C
B A
C
available
SW1-2
SW1-1
unavailable
2nd level
3rd level
OFF
OFF
0150519911
CN16
ELECTRIC HEATING TERMINAL
RATING_12VDC
CONNECT TO THIRD PARTY RELAY
CAPACITY (KW)
/
/ / /
