Haier Smart Power Series User Manual

49
Smart Power
6. Instalaltion
6.1 Safety Precautions
The machine is adaptive in following situation
1. Applicable ambient temperature range:
2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similar qualied
person.
3. If the fuse on the indoor PC board is broken please change it with the type of T3.15A /250V(For ADH105,
ADH125,ADH140M1ERG); or the type T5A /250V(For ADH071M1ERG,ADH071M3ERG,ADH090M1ERG).
4. The wiring method should be in line with the local wiring standard.
5. The power cable should be:
H05RN-F 3G 4.0mm
2
(outdoor unit 1UH071/090/105N1ERG),
or H05RN-F 3G 6.0mm
2
(outdoor unit 1UH125/140P1ERG),
or H05RN-F 5G 4.0mm
2
(outdoor unit 1UH125/140P1EK);
The connecting cable should be:
H05RN-F4G 2.5mm
2
;
All the cables shall have got the European authentication certicate. During installation, when the connecting
cables break off, it must be assured that the grounding wire is the last one to be broken off.
6. The power cable and connect cable should be self-provided.
7. The breaker of the air conditioner should be all-pole switch, and the distance between its two contacts should be
no less than 3mm.
8. The indoor unit installation height is at least 2.5m.
9. A leakage breaker must be installed.
10.10.1 FOR ADH071M1ERG, ADH090M1ERG, we can get the 4 different ESP through adjust the indoor unit PCB
SW1-4 and SW1-5, please refer below:
Attention:
Cut off the power supply to adjust the SW1-4, and SW1-5, or else the operation is invalid.
10.2 For ADH071M3ERG, ADH105M1ERG, ADH125M1ERG, ADH140M1ERG ,static pressure selection need
achieved by wired controller, refer wired controller's manual to get details
Cooling
Indoor temperature
max. DB/WB
min. DB/WB
32/23°C
18/14°C
Outdoor temperature
max. DB/WB
min. DB/WB
43/26°C
10/6°C
Heating
Indoor temperature
max. DB/WB
min. DB/WB
27°C
15°C
Outdoor temperature
max. DB/WB
min. DB/WB
24/18°C
-15°C
SW1
Static pressure
(1) (2) (3) (4) (5) (6) (7) (8)
- - - OFF OFF - - - 10 Pa
- - - OFF ON - - - 30 Pa
- - - ON OFF - - - 50 Pa
- - - ON ON - - - 70 Pa
