Smart Power
Item Model ABH090H1ERG/1UH090N1ERG
Function Cooling Heating
Capacity kW 9 (2.5~10) 10.1 (2.5~11)
Sensible heat ratio 0.72 /
Total power input kW 2.56 (0.5~3.5) 2.69 (0.5~3.5)
Max. power input W 4400
AEER or ACOP W/W 3.44 3.87
Dehumidifying capacity 10
-3
×m
3
/h 2.5
Power cable 4.0mm
2
Power source N, V, Hz 1PH, 220-240V~, 50/60Hz
Running/Max. Running current A/A 11.6 (2.3-19.2)/19.2 11.9 (2.3-19.2)/19.2
Start current A 3
Circuit breaker A 30
Indoor unit
Unit model (color) ABH090H1ERG
Fan
Type×Number CENTRIFUGALX1
Speed (H-M-L-SL) r/min 600/500/400/350
Fan motor output/input power W 77/125
Air-ow (H-M-L-SL) m
3
/h 1470/1260/1050/940
Heat
exchanger
Type/Diameter mm Inner grooved pipe/φ7.0
Row 2
Total area m
2
/
Dimension
External (L×W×H) mm×mm×mm 840/840/246
Package (L×W×H) mm×mm×mm 990/990/310
Drainage pipe (material, I.D./O.D.) mm PVC 26/32
Controller (O-Optional, S-Standard)
Wired YR-E16A(O)/YR-E17(O)
Infrared YR-HBS01(S)
Fresh air hole dimension mm 75
Electricity heater kW /
Sound power noise level (H) dB (A) 57
Sound pressure noise level (H-M-L-SL) dB (A) 41/36/33/29
Weight (Net/Shipping) kg/kg 31/36
Panel
Model PB-950KB/PB-950MB
External dimensions (W/D/H) mm 950/950/50
Shipping dimensions (W/D/H) mm 1000/1000/110
Net weight/Shipping weight kg 6.5/9
Piping
Refrigerant
Type/Charge g R410A/2500
Recharge quantity g/m 45
Pipe
Liquid mm 9.52
Gas mm 15.88
Max pipe length
(without charge refrigerant)
m 20
Between
I.D &O.D
MAX. Drop m 30
MAX. Piping length m 50
Connection method Flared
Cooling Pdesignc (kW) : 9kW SEER/CLASS 6.3/A++
QCE (Annual electricity
consumption for cooling)
kWh:
516
Heating
Average Pdesignh (-10°C) 8.1kW SCOP/CLASS 4.1/A+
QHE (Annual electricity
consumption for heating)
kWh:
2798
Warmer Pdesignh (2°C) 8.8kW SCOP/CLASS 4.8/A++ 2416
Colder Pdesignh (-22°C) / SCOP/CLASS / /
Tdesignh: -10°C Tbivalent: -8°C TOL: -20°C Elbu: 0
Max. cooling condition
Indoor temperature: 32°C/23°C Max. heating
condition
Indoor temperature: 27°C/-°C
Outdoor temperature: 46°C/-°C Outdoor temperature: 24°C/18°C
Norminal condition:
Indoor temperature (cooling) : 27DB (°C)/19WB (°C) , Indoor temperature (heating) : 20DB (°C)
Outdoor temperature (cooling) : 35DB (°C)/24WB (°C) , Outdoor temperature (heating) : 7DB (°C)/6WB (°C)
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated sound intensity meter.
It is a sound pressure noise level.
