14
Smart Power
Item Model ABH140K1ERG/1UH140P1ERK
Function Cooling Heating
Capacity kW 13.4 (3.5~15.0) 14.5 (4.0~18.0)
Sensible heat ratio 0.74
Total power input kW 4.05 4.11
Max. power input W 7200
AEER or ACOP W/W 3.27 3.48
Dehumidifying capacity 10
-3
×m
3
/h
Connection cable（
from outdoor to indoor)
Power source N, V, Hz
4.9
H05RN-F 4G 2.5mm2
3PH~, 380~415, 50/60Hz
Running/Max. Running current A/A 6.8/11.0 7.0/11.0
Start current A 3
Circuit breaker
A
Indoor unit
Unit model (color)
Fan
Type×Number
Speed (H-M-L)
r/min
3Ph,40A （
from outdoor）
ABH140K1ERG
CENTRIFUGALX1
750/650/550
Fan motor input power kW 0.12
Fan motor output power kW 0.09
Air-ow (H-M-L) m
3
/h 1950/1600/1440
Heat
exchanger
Type/Diameter mm Inner grooved pipe/φ7.0
Total area
m
2
/
Dimension
External (L×W×H) mm×mm×mm 840/840/288
Package (L×W×H) mm×mm×mm 990*990*380
Drainage pipe (material, I.D./O.D.) mm PVC 21/25
Controller (O-Optional, S-Standard)
Wired YR-E17(O) OR YR-E16A(O)
Infrared YR-HBS01 (S)
Fresh air hole dimension mm 75
Electricity heater kW /
Sound power noise level (H-M-L) dB (A) 64
Sound pressure noise level (H-M-L) dB (A) 48/45/42
Weight (Net/Shipping) kg/kg 32/38
Panel
Model PB-950KB/PB-950KB
External dimensions (W/D/H) mm 950/950/50
Shipping dimensions (W/D/H) mm 1000/1000/110
Net weight/Shipping weight kg 6.5/9.0
Piping
Refrigerant
Type/Charge g R410A/3700
Recharge quantity g/m 45
Pipe
Liquid mm 9.52
Gas mm 15.88
Max pipe length
(without charge refrigerant)
m 30
Between I.D
&O.D
MAX. Drop m 30
MAX. Piping length
m
75
Connection method Flared
Norminal condition:
Indoor temperature (cooling) : 27DB (°C)/19WB (°C) , Indoor temperature (heating) : 20DB (°C)
Outdoor temperature (cooling) : 35DB (°C)/24WB (°C) , Outdoor temperature (heating) : 7DB (°C)/6WB (°C)
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated sound intensity
meter. It is a sound pressure noise level.
