67
Smart Power
Item Model ADH250H1ERG/1UH250W1ERK
Function Cooling Heating
Capacity kW 24(7.2-26.5) 26.8(8.2-28.8)
Sensible heat ratio / /
Total power input kW 7.47(3.5-9.5) 7.18(3.5-9.5)
Max. power input W 9500 9500
EER or COP W/W 3.21 3.73
Dehumidifying capacity 10
-3
×m³/h 7.1
Power source N, V, Hz 1PH, 220-230V~, 50/60Hz
Running /Max.Running current A / A 12.0(2.2-16.3)/16.3 11.8(2.2-16.3)/16.3
Start Current A /
Circuit breaker A
3Ph, 40A（
from outdoor）
Indoor unit
Unit model (color) ADH250H1ERG/(grey)
Fan
Type × Number CENTRIFUGALX2
Speed(H-M-L) r/min 1060/980/900
Fan motor input power W 980/1225
Fan motor output power Pa 72PA(default)
Air-ow(H-M-L) m³/h 5040/4500/3960/3600
Heat
exchanger
Type/Diameter mm Inner grooved pipe/φ7.0
Row 4
Total area m² /
Dimension
External(L×W×H) mm×mm×mm 1330/895/500
Package(L×W×H) mm×mm×mm 1510/1037/568
Drainage pipe (material, I.D./O.D.) mm Hot zinc plate 23/25
Controller (O-Optional,S-Standard)
Wired(S) YR-E17(S) OR YR-E16A(O)
Infrared(O) YR-HBS01
Fresh air hole dimension mm /
Electricity heater kW None
Sound power noise level (H-M-L) dB(A) 69
Sound pressure noise level (H-M-L) dB(A) 55/51/47
Pipe
Liquid pipe mm 12.7
Gas pipe mm 22.2
Connecting method ared/or welding
Weight (Net / Shipping) kg / kg 96/125
Tdesignh: -10°C Tbivalent: -10°C TOL:-15°C Elbu:0
Max. cooling condition
Indoor temperature:18~32°C
Max. heating
condition
Indoor temperature:27°C/-°C
Outdoor temperature:-10~46°C
Outdoor temperature:24°C/18°C
Norminal condition:
indoor temperature (cooling): 27°C DB/19°C
WB, indoor temperature (heating): 20°C DB
Outdoor temperature (cooling): 35°C DB/24°C WB, outdoor temperature (heating): 7°C DB/6°C WB
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated
sound intensity meter. It is a sound pressure noise level.
