Item Model AD18SS1ERA(N)(P)
Function cooling heating
Capacity KW 5.0(1.8~6) 5.5(2~6.2)
Sensible heat ratio 0.73 /
Total power input KW 1.53(0.55~2.1) 1.47(0.6~2.1)
Max. power input W
2100 2100
EER or COP W/W 3.26 3.73
Dehumidifying capacity 10-³×m³/h 1.9
Power cable H05RN-F 4G 4.0mm
2
Power source N, V, Hz
1PH, 220-230V~, 50/60Hz
Running /Max.Running current A / A 6.8(2.3-9.5)/9.5 6.5(2.39.5)/9.5
Start Current A 3
Circuit breaker A / /
Indoor unit
Unit model (color) AD18SS1ERA(N)(P)
Fan
Type × Number CENTRIFUGALX3
Speed(H-M-L) r/min 950/850/750
Fan motor output/ input power W 124/74
Air-ow(H-M-L) m³/h 900/750/600
ESP Pa 0/10/20/30
Heat
exchanger
Type / Diameter mm inner grooved pipe/φ7.0
Row 3
Total Area m² /
Dimension
External(L×W×H) mm×mm×mm 1170/420/185
Package(L×W×H) mm×mm×mm 1365/540/270
Drainage pipe (material , I.D./O.D.) mm
PVC 25/29
Controller
(O-Optional,S-Standard)
Wired YR-E14(S)
Infrared YR-HD(O)
Fresh air hole dimension mm NONE
Electricity Heater kW NONE
Sound power Noise level (H-M-L) dB(A) 49/43/39
Sound pressure Noise level (H-M-L) dB(A) 36/30/26
Pipe
Liquid Pipe(mm)
6.35
Gas Pipe(mm)
12.7
Connecting Method
ared
Weight (Net / Shipping) kg / kg 22.8/28.5
