Haldex EB Plus - ECU Connector Identification; Auxiliary and Sensor Connectors; System Power and Interface Connectors

12
Fig 10
ISO 7638
ISO 1185
(24N)
Green
Orange
Blue
Pressure
switch -
Option
Ref Page 22
SENSOR 1A
SENSOR 2A
SENSOR 2B
SENSOR 1B
Blanking plugs
Blue
Blue
Black
ECU Connector Identification
EB
+
INFO
CENTRE
or
PC
Interface
Auxiliary connectors
Blanking
plug
OPTIONS
Tacho
COLAS®
Retarder
Trailer lamp
ILAS®-E front
ILAS®-E rear
Aux power
Steer axle lock
Lining Wear Lamp
Overload lamp
Auxiliary
connector AUX 1
Black
Blue
OPTIONS (AUX 5)
EB+ Stability (2M Semi -Retrofit)
OPTIONS (AUX 4)
Lining Wear System
OPTIONS (AUX 2 & 3)
Tacho COLAS®
Trailer lamp Retarder
ILAS®-E front ILAS®-E rear
Aux power Steer axle lock
System - 3M (Full Trailers)
Red
Red
Slave ECU (1M) Master ECU (2M)
ISO
7638
Blue
3M LINK POWER 'B'
B Sensors
B Sensors
A Sensors
A Sensors
Lining wear lamp
Overload lamp
ILAS®-E Front Manual
ILAS®-E Rear Manual
Blanking
plug
