Haldex EB+ Gen 2 - ECU Connector and AUX Port Identification; AUX 1 Functions; AUX 2, AUX 3 Functions; AUX 4 Functions

11
Pin1Pin4
ISO1185
ISO 7638
Info Centre
Sensor S1A
Sensor S2A
Sensor S1B
Sensor S2B
Fig. 15
AUX 1
Colas, Reset-to-Ride
Height
Retarder Control
24 V Power Output
Trailer Lamp
ILAS-E Front
ILAS-E rear
Aux Power
Steer Axle Lock
Service Lamp
Overload Lamp
Remote Overload Lamp
Stability Lamp
Lining Wear Lamp
General Purpose Output
Info Point
Tachometer
AUX 2, AUX 3
Colas, Reset-to-Ride
Height
Retarder Control
24 V Power Output
Trailer Lamp
ILAS-E Front
ILAS-E rear
Aux Power
Steer Axle Lock
Service Lamp
Overload Lamp
Remote Overload Lamp
Stability Lamp
ILAS-E Front manual
ILAS-E Rear Manual
General Purpose Output
AUX 4
Lining Wear sensor
General Prupose Input
Control Line Sensor
Soft Docking
Electronic Height Sensor
AUX 5
Lateral Accelerometer
General Purpose Input
Control Line sensor
Soft Docking
Electronic Height Sensor
PC Interface
ISO Interface
assembly
PC
Interface
ECU Connector Identification
