Haldex EB+ Gen 2 - Piping Diagram (4 S;2 M with REV); Key and Component List; Emergency and Service Lines

13
Fig. 17
Side by Side configuration,
3 axle Semi-Trailer - 2 line air brake system
Item Description Notes
1 Emergency Coupling
2 Service Coupling
3 Pipe Filter
4 Combined Park and Shunt Valve 352-044-... / 352-045-...
5 Air Reservoir
6 Drain Valve
7 Test Point
8 EB+ Gen 2 Assembly
9 Spring Brake Chamber
10 Single Diaphragm Brake Chamber
11 Relay Emergency Valve
12 Suspension Bellows
5
6
Emergency
Service
3
3
1
2
4
7
7
7
8
7
10
10 9 9
9
9
22
11
1
4
1
1
2
2
41
21
21
21
11 12
11 12
11 12
11 12
1
1
22
22
22
4
11
23
23
23
21
1
2-1
2
11
12
23
Key: Item no. Port No.
1
1
Piping Diagram
4S/2M - Side-by-Side Configuration with REV
