Haldex EB+ Gen 2 - Piping Diagram (2 M with Park;Shunt Valve); Key and Component List; Emergency and Service Lines

16
Key: Item no. Port No.
1
1
Piping Diagram
2M, Side-by-side with Individual Park & Shunt
Fig. 20
Side by Side configuration,
3 axle Semi-Trailer - 2 line air brake system - Spring brake chambers
Item Description Notes
1 Emergency coupling
2 Service coupling
3 Pipe filter
4 Shunt Valve
5 Air Reservoir
6 Drain valve
7 Test Point
8 EB+ Gen 2 Assembly
9 Spring Brake Chamber
10 Single Diapragm Brake Chamber
11 Suspension Bellows
12 Relay Emergency Valve (REV)
13 Park Valve
14 Test Point Simulator
15 Single Check Valve (optional)
6
Emergency
Service
3
3
1
2
4
11
7
7
8
10
10 9 9
9
9
11
4
1
1
2
2
41
23
11
11 12
11 12
11
1
1
22
4
2-1
2
14
12
12
23
22
11
23 23
1
21
22
21
7
2
12
1
2
12
2
13
15
7
5
12
