Segmentation Capability:
 Able to transmit segmented messages Window Size
 Able to receive segmented messages Window Size 1024
Standard Object Types Supported:
Object Type Supported Can Be Created Dynamically
Can be Deleted Dynamically
Analog Input
No No
Binary Value Yes Yes
Multi State Value
No No
Data Link Layer Options:
BACnet IP, (Annex J)
 BACnet IP, (Annex J), Foreign Device
 ISO 8802-3, Ethernet (Clause 7)
 ATA 878.1, 2.5 Mb. ARCNET (Clause 8)
 ATA 878.1, EIA-485 ARCNET (Clause 8), baud rate(s) ____________
 MS/TP master (Clause 9), baud rate(s):
 MS/TP slave (Clause 9), baud rate(s):
 Point-To-Point, EIA 232 (Clause 10), baud rate(s):
 Point-To-Point, modem, (Clause 10), baud rate(s):
 LonTalk, (Clause 11), medium: __________
 BACnet/ZigBee (ANNEX O)
 Other:
Device Address Binding:
Is static device binding supported? (This is currently necessary for two-way communication with MS/TP slaves
and certain other devices.)  Yes  No
Networking Options:
 Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.
 Annex H, BACnet Tunneling Router over IP
 BACnet/IP Broadcast Management Device (BBMD)
Does the BBMD support registrations by Foreign Devices?  Yes  No
Does the BBMD support network address translation?  Yes  No
Network Security Options:
 Non-secure Device - is capable of operating without BACnet Network Security
 Secure Device - is capable of using BACnet Network Security (NS-SD BIBB)
 Multiple Application-Specific Keys:
 Supports encryption (NS-ED BIBB)
 Key Server (NS-KS BIBB)
