Character Sets Supported:
Indicating support for multiple character sets does not imply that they can all be supported simultaneously.
ISO 10646 (UTF-8) IBM
/Microsoft
DBCS ISO 8859-1
ISO 10646 (UCS-2) ISO 10646 (UCS-4) JIS X 0208
If this product is a communication gateway, describe the types of non-BACnet equipment/networks(s) that
the gateway supports: N/A
BACnet IP Mapping:
V2.2 - 9/09/2020
Name Object Type Instance ID Units Raw Sensor Ranges
Temperature (F) AnalogInput 1 Degrees Fahrenheit -40 – 185 °F
Temperature (C) AnalogInput 17 Degrees Celsius -40 – 85 °C
Relative Humidity AnalogInput 2 % Relative Humidity 10 – 100% rh (between 0 and 60 °C)
Visible Light AnalogInput 3 Luxes 0 – 30,000 Lux
TVOC AnalogInput 4 ppb 0 – 60,000ppb
CO2 eq AnalogInput 5 ppm 400 – 60000ppm (eq)
Sm Particulates (1um) AnalogInput 6 μg/m^3 0 – 500 μg/m^3
Md Particulates (2.5um) AnalogInput 7 μg/m^3 0 – 500 μg/m^3
Lg Particulates (10um) AnalogInput 8 μg/m^3 0 – 500 μg/m^3
Ammonia AnalogInput 9 ppm 0.5 – 100 ppm
NO2 AnalogInput 10 ppb 40 – 7,000 ppb
CO AnalogInput 11 ppm 0.1 – 500 ppm
Noise Level AnalogInput 12 dB 20 – 130dB SPL
High Gain Mic AnalogInput 13 dB 20 – 100dB SPL
Low Gain Mic AnalogInput 14 dB 50 – 130dB SPL
AQI AnalogInput 15 No Units
Pressure AnalogInput 16 Inches of Mercury 9 – 33 inHg
Name
Instance ID
event_Gunshot
1
event_Help
2
event_Vape
3
event_THC
4
event_Masking
5
event_Aggression
6
event_Tamper
7
event_AQI
11
event_USER_EVENT_1
1000
event_USER_EVENT_2
1001
Name
Instance ID
event_TVOC
8
event_CO2eq
9
event_CO
10
event_Help000
12
event_Temp_F
13
event_Temp_C
14
event_Light
15
event_PM1
16
event_PM2.5
17
event_PM10
18
event_NH3
19
event_NO2
20
event_Noise
21
event_Pressure
22
event_Humidity
23
Name
Instance ID Description State Values
AQI Source
1
Largest Value
Contributing to Air
Quality Index
Unavailable,PM2.5, PM10, CO,
NO2
