Hampton
®
H27E-11 Direct Vent Freestanding Gas Stove | 3
table of contents
On Demand Pilot Light (seven day safety timer)
Important information if using the appliance in CPI (continuous pilot mode) only
This appliance is a ProFlame 2 system fitted with the “On Demand” Pilot, a safety feature which will shut down the gas valve completely
by extinguishing the pilot light in the event of a continuous full seven days of inactivity.
This only applies if the CPI (continuous pilot) switch is in the “on” position in your remote control transmitter.
Each time the main burner shuts down, manually or through the call from the thermostat, the seven day timer starts again.
The seven day inactivity timer is controlled within the circuit board. Therefore, if in CPI mode and when the pilot light is extinguished
after seven straight days of inactivity, the CPI setting on the remote control transmitter will remain in the “CPI” (continuous pilot) position.
Therefore, all that is required to relight the pilot would be to press the on/off button on the remote control transmitter from “on” to “off” and
back to “on”. Once the pilot has re-established operation will resume as normal. There is no requirement to do anything with the IPI/CPI
mode on the remote control transmitter.
If the unit never goes as long as seven full days without a call for heat, the pilot will remain lit until it is manually shut-off.
If the unit is being operated in IPI (intermittent pilot) mode, neither the above instructions nor the seven day timer will apply.
See the instructions in this manual and on the Lighting Instructions plate on the appliance to light or re-light the pilot.
General Safety Information ..........................................14
Installation Checklist ....................................................14
Clearances to Combustibles ........................................15
Locating Your Gas Stove..............................................15
Manufactured Mobile Home Additional Requirements 15
Combustion and Ventilation Air ....................................15
Accent Light Bulb Install ..............................................15
Optional Fan Installation ..............................................16
Glass Front Removal / installation ...............................17
Venting Introduction .....................................................18
Installation Precautions ...............................................18
Safety Precautions for the Installer ..............................18
Vent Restrictor Position ...............................................18
Rotating 45
o
Elbow ......................................................18
Exterior Vent Terminal Locations .................................19
4” x 6-5/8” Rigid Pipe Cross Reference Chart .............20
Rigid Pipe Venting Systems .........................................22
Venting Arrangements .................................................23
Vertical Termination with Co-linear Flex System ..........26
DV Stove Horizontal Vent Kit Installation .....................27
Residential and Manufactured Homes/Mobile Homes 29
On Demand Pilot Light (seven day safety timer) ...........3
Copy of the Safety Decal ...............................................4
Unit Dimensions with Vertical Venting ............................6
Unit Dimensions with Horizontal Venting .......................6
Important Message ......................................................7
Specifications ................................................................7
Information for Mobile / Manufactured Homes After First
Sale ...............................................................................7
Before You Start .............................................................7
Lighting / Shutdown Procedure .....................................8
Copy of the Lighting Plate Instructions .........................9
Proflame II Remote Control Operating Instructions ....10
Warranty ......................................................................52
Dura-Vent Termination Kit ............................................30
Horizontal terminations ................................................31
Vertical Terminations ...................................................32
Converting Class-A Metal Chimney to Direct Vent System
.....................................................................................34
Cathedral Ceilings .......................................................35
High Elevation ..............................................................35
Gas Connection ...........................................................35
Aeration Adjustment ....................................................36
Gas Pipe Pressure Testing ..........................................36
885 S.I.T. Valve Description .........................................36
Conversion Kit from NG to LP .....................................37
Log Set Installation ......................................................38
Optional Wall Thermostat ...........................................40
Remote/IFC Coding .....................................................40
Manual Operation (No Remote) ..................................40
Final Check ..................................................................40
Back Up Battery...........................................................40
Wiring Diagram Without Thermostat ............................41
Wiring Diagram With Thermostat .................................42
First Fire ......................................................................43
Operating Instructions .................................................43
Operation Using an Optional Wall Thermostat ............43
Lighting / Shutdown Procedure ...................................44
Copy of the Lighting Plate Instructions .......................45
Normal Operating Sounds of Gas Appliances .............46
Maintenance Instructions ............................................46
Flame Pattern ..............................................................46
General Vent Maintenance ..........................................47
Log Replacement ........................................................47
Glass Replacement .....................................................47
Fan Maintenance .........................................................47
Safety Screen Removal / Installation ...........................48
Valve Assembly Replacement .....................................48
Accent Light Bulb Replacement ..................................48
Main Assembly ............................................................49
Burner & Log Assembly ...............................................50
Warranty ......................................................................52
Owner's Information
Installer's Information
