Hampton
®
H27E-11 Direct Vent Freestanding Gas Stove | 39
installation
03/17/09918-104a
H25 / H27
Page 2 of 2
5) Take the embers and place on the burner in the space be-
tween the 2 front logs. Do not put embers on the burner in
the area between the front logs and the rear log. See photo
below.
Separate platinum e mbers and place at t he front o f the burner
in and around where the embers are placed. Avoid stacking
platinum embers.
6) Place the center cross log D so it rests in the notch located
on the top of the rear log - position as shown below.
Logs must be oriented as shown below.
7) Test fi re to ensure proper light off (make sure fl ame fl ows
smoothly from one end of burner to the other). If there is
any fl ame hesitation, check that area for any blockage of
the burner ports.
8) Re-install the Glass door and Cast Front and Cast Top.
B
C
Platinum
Embers
Embers Embers
D
A
A
B
C
D
