Hamworthy F175V - Appendix A Gas Data

HAMWORTHY HEATING LTD
43
FLEET V series 500001217/D
APPENDIX A - GAS DATA
GENERAL DATA
BOILER MODEL
F175V-350
F175V-525
F200V-400
F200-V600
Boiler Input (maximum) - kW (Gross) 359.7 539.5 411.1 616.6
Boiler Input (maximum) - kW (Nett) 324.1 486.1 370.4 555.6
Boiler Output (maximum) condensing 50/30°C - kW 350 525 400 600
Boiler Output (maximum) non condensing 80/60°C - kW 316.6 474.9 361.8 542.7
Boiler Module Output (minimum) 80/60°C - kW 31.7 31.7 36.2 36.2
Boiler Module Output (minimum) 50/30°C - kW 35.0 35.0 40.0 40.0
F250V-500
F250V-750 F300V-600 F300V-900
Boiler Input (maximum) - kW (Gross) 513.8 770.7 616.6 924.9
Boiler Input (maximum) - kW (Nett) 462.8 694.2 555.6 833.4
Boiler Output (maximum) condensing 50/30°C - kW 500 750 600 900
Boiler Module Output (minimum) 80/60°C - kW 45.2 45.2 54.3 54.3
Boiler Output (maximum) non condensing 80/60°C - kW 452.4 678.6 542.7 814.2
Boiler Module Output (minimum) 50/30°C - kW 50.0 50.0 60.0 60.0
F350V-700
F350V-1050
Boiler Input (maximum) - kW (Gross) 719.3 1079.0
Boiler Input (maximum) - kW (Nett) 648.2 972.3
Boiler Output (maximum) condensing 50/30°C - kW 700 1050
Boiler Output (maximum) non condensing 80/60°C - kW 633.2 949.8
Boiler Module Output (minimum) 80/60°C - kW
63.3 63.3
Boiler Module Output (minimum) 50/30°C - kW
70.0 70.0
Figure A1– Gas data
F300V
F350V
Gas Inlet Connection Pipe Thread Size
R 1¼” R 1¼”
Nominal Inlet Pressure Nat Gas -mbar
20
Maximum Inlet Pressure Nat Gas -mbar 25
Gas Pressure Switch Setting Nat Gas -mbar 12.5
Gas Flow Rate (max. per module) Nat Gas -m
3
/h 29.3 34.2
Target CO
2
% at High / Low fire Nat Gas ±0.25%
9.2 / 10.0
GAS DATA - per boiler module
F175V
F200V
F250V
Gas Inlet Connection Pipe Thread Size
R 1” R 1” R 1”
Nominal Inlet Pressure Nat Gas -mbar
20
Maximum Inlet Pressure Nat Gas -mbar 25
Gas Pressure Switch Setting Nat Gas -mbar
12.5
Gas Flow Rate (max. per module) Nat Gas -m
3
/h
17.1 21.7 24.4
Target CO
2
% at High / Low fire Nat Gas ±0.25%
9.2 / 10.0
