FLEET V series
500001217/D
Figure 2.2 - Boiler Packaged Dimensions
Delivery Verification
When taking delivery please ensure that you have received the correct number of boilers and individual flue kits to
fulfil your order. If any item is missing please contact our after sales service team. Please provide details of your
order such as order number and contract number as well as a detailed description of the missing item.
Frame Set and Pipe work Header Kits
Where pipe work kits are supplied, these are packaged separately from the boilers. All ancillary items such as
isolation valves and boiler make-up connectors are factory fitted and tested The whole is shrink wrapped for security and
basic protection. Refer to Kit instructions 500005134 for specific information.
Model H mm W mm D mm Weight (kg)
F175V-350 1505 880 1235 412
F200V-400 1505 880 1235 440
F250V-500 1505 880 1235 500
F300V-600 1505 880 1515 554
F350V-700 1505 880 1515 614
F175V-525 2110 880 1235 610
F200V-600 2110 880 1235 653
F250V-750 2110 880 1235 738
F350V-1050 2110 880 1515 908
Flue manifold 900 300 300 10
F300V-900 2110 880 1515 818
