OPERATION (Continued)
TRANSPORT LOCKS, FRONT & REAR
RAKE BEAM LOCKS
Transport locks are mounted to the front of the pole. (A) Shows the rake locked into transport position. (B)
Shows the transport locks in the convenient storage postion, to be used when in the raking mode.
RAKE WHEEL LOCKS
Located at the rear of the lift pipe, is a hair pin which is used to secure the rake wheels in the up position
for transport (C). When in the down, or raking position, place the locking hair pin in the convenient storage
position as shown (D).
A B
CD
