H&S 1460 - Page 23

FIGURE 1
1460-1660 HI-CAPACITY RAKE
BEAMS AND LINKAGE
ITEM PART NO. DESCRIPTION
1. BFR473 Front Rake Beam LH
2. BFR475 Back Rake Beam LH
3. BFR472 Front Rake Beam RH
4. BFR474 Back Rake Beam RH
5. BFR745 Rake Beam Arm LH
6. BFR744 Rake Beam Arm RH
7. BFR458 Front Linkage
8. BFR463 Left Rear Linkage
9. BFR462 Right Rear Linkage
10. BFR455 Front Linkage Slider
11. BFR491 Back Linkage Slider
12. BFR465 Center Slider
13. BFR616 Width Adjustment Stop
14. BFR477 Back Linkage Yoke LH
15. BFR480 Left Pivot Yoke Shaft
16. BFR476 Back Linkage Yoke RH
17. BFR505 Pivot Yoke Shaft Pin LH
18. BFR479 Pivot Yoke Shaft Pin RH
19. BFR468 Linkage Pins
20. BFR716 Center Slider Pin
21. BFR467 Center Slider Spacer
22. BFR471 Back Slider Roller
23. BFR457 Slider Spacer
24. BFR456 Hose Guide Spacer
25. BFR426 Rake Pressure Handle
26. BFR486 Rake Arm Lock-up Shaft
27. BFR530 Hydraulic Cylinder End Slide LH
* BFR531 Hydraulic Cylinder End Slide RH
28. BFR83 Pipe Clamp (2 Holes)
29. BFR430 RH Spring Bracket
30. BFR84 Compression Spring
31. BFR431 LH Spring Bracket
32. BFR432 LH Lifting Pipe Connector
* BFR433 RH Lifting Pipe Connector
33. BFR521 Lifting Pipe Back
34. BFR520 Lifting Pipe Front
35. BFR549 Tooth Deflector
36. BFR726 Right Extension
37. BFR727 Left Extension
38. BFR443 Lynch Pin
39. BFR612 Side Arm Stabilizer Rod
40. X94 Cylinder Spacer
41. K106 Cylinder Spacer
42. BFR312 Complete Fork RH
* BFR316 Complete Fork LH
43. BFR57 Seal
44. BFR58 Inner Bearing
45. BFR59 Inner Race
46. BFR60 Hub
47. BFR61 Outer Race
NOTE: * (MEANS NOT SHOWN)
ITEM PART NO. DESCRIPTION
48. BFR62 Outer Bearing
49. BFR63 Washer
50. BFR65 Cotter Pin
51. BFR64 Nut
52. BFR66 Hub Cap
53. BFR144 Nut
54. BFR143 Stud
55. BFR527 Bronze Bushing
56. BFR309 Gauge Wheel Washer
57. BFR311 Brake Collar
58. BFR489 Rake Arm LH
* BFR490 Rake Arm RH
59. BFR657 Rake Wheel Hub
60. F16 Lock Collar
61. BFR525 Bearing
62. FR44 Rake Arm Spring
63. BFR140 Rake Arm Adjusting Chain
64. FR71 Rake Wheel Center
65. FR72 Outer Ring
66. FR73 Rake Wheel Tooth
67. FR74 Rake Tooth Clip
68. T175 10mm x 25mm Carriage Bolt
69. BFR652 10mm Lock Nut
* FR69 Rake Wheel LH
* FR70 Rake Wheel RH
70. DF22 Washer
71. BFR461 Rake Beam Arm Pin
72. 16SV171A Hydraulic Lift Cylinder (2”x10”)
73. BFR82 Pipe Clamp (1 Hole)
74. BFR693 Stop Washer
75. BFR506 Nylon Wear Block
76. 23N108 Cotter Pin
77. BFR137 Hair Pin
78. BFR517 Cylinder Pin - Back
79. 16SV77 1/2” x 6” Bolt GR. 5
80. ES7 Hair Pin
81. BFR7 3/16” x 3-3/4” Cotter Pin
82. BFR481 1-1/2” Slotted Nut
83. BFR111 Back Rake Arm Adjustment Chain
84. T143 Cylinder Pin
85. 16SV136 Washer
86. BFR494 1/2” x 6-1/2” Bolt GR. 5
87. BFR641 Washer
88. BFR597 Safety Bar
90. BFR729 Rake Arm Stop
91. BFR716 3/4” Flange Nut
92. BFR438 5/8”x2” Bolt GR. 5
93. RG24 Bronze Washer
94. BFR310 Brake Pad (2)
95. BFR313 5/16”x2-3/4” Roll Pin
96. RG24 Bronze Washer
-21-
