H&S 1460 - Page 25

FIGURE 2
1460-1660 HI-CAPACITY RAKE
MAIN FRAME
ITEM PART NO. DESCRIPTION
1. BFR730 Pole
2. BFR714 Center Pole Section
3. BFR715 Back Pole Section
4. BFR709 Rear Pivot Assembly
5. BFR662 Left Axle Upright
6. BFR661 Right Axle Upright
7. BFR711 Center Pole Brace-Removable
8. BFR710 Back Pole Brace-Removable
9. BFR510 LH Tandem Axle
10. BFR509 RH Tandem Axle
11. BFR611 Width Adjustment Bar
12. BFR712 Middle Linkage Stop
13. BFR157 Hitch
14. BFR499 Beam Pivot Shaft
15. BFR239 Sleeve Adjustment Lock
16. BFR241 Adjustment Handle
17. BFR240 Spring
18. BFR423 Width Adjustment Handle
19. BFR485 Rear Width Adjustment Tube
20. BFR523 Poly Washer
21. BFR422 Width Adjustment Collar
22. BFR419 3/4” Acme Nut
23. BFR524 Tandem Pin
24. BFR625 Bushing
25. BFR57 Seal
26. BFR58 Inner Bearing
27. BFR59 Inner Race
28. BFR60 Hub
29. BFR61 Outer Race
30. BFR62 Outer Bearing
31. BFR63 Washer
32. BFR64 Nut
33. BFR66 Hub Cap
ITEM PART NO. DESCRIPTION
34. BFR65 Cotter Pin
35. BFR144 Nut
36. BFR143 Stud
37. BFR223 Jack
38. BFR450 Hitch Pins
39. BFR67 Wheel (15 x 5)
40. BFR128 Tire (6.70 x 15)
41. BFR653 Hydraulic Cylinder (2” X 40”)
42. HE42 Hose Holder
43. BFR649 SMV Bracket
44. BFR420 Rear Width Adjustment Rod
45. BFR522 Spindle
46. BFR396 Cylinder Pin
47. 12N14 Jack Mount
48. BFR4 Jack Pin & Chain
49. B17B Jack Handle
50. BFR107 3/4” x 8-1/2” Bolt GR. 5
51. BFR518 3/4” - 16 nut
52. BFR634 Front Width Cylinder Pin
53. BFR724 Self Tapping Bolt
54. BFR642 Width Adjustment Spacer
55. 23N67 Hose Holder
56. RG135 1/2” x 1” Bolt GR. 5
57. 50N129 3/4” x 6” Bolt GR. 5
58. BFR438 5/8” x 2” Bolt GR. 5
59. 12V59 3/8” x 2-3/4” Roll Pin
60. BFR117 3/8” x 2-1/2” Bolt GR. 5
61. BFR534 Pole Extension
62. BFR731 Transport Mount
63. BFR732 Width Stop Ring
64. 12V59 3/8” x 2-3/4” Roll Pin
65. BFR420 Rear Width Adjustment Rod
-23-
