FIGURE 6
1460-1660 HI-CAPACITY RAKE
2-WHEEL EXTENSION KIT
ITEM PART NO. DESCRIPTION
1. BFR733 Rake Beam Extension RH
2. BFR534 Pole Extension
3. BFR734 Rake Beam Extension LH
4. BFR537 Lifting Pipe Connector
5. BFR431 LH Spring Clamp
* BFR430 RH Spring Clamp
6. BFR536 Lifting Pipe Extension
7. BFR735 Complete Extension Kit
8. BFR525 Bearing
9. F16 Lock Collar
10. BFR489 Rake Arm LH
* BFR490 Rake Arm RH
11. BFR140 Rake Arm Adjustment Chain
12 FR44 Spring
13. FR69 Rake Wheel LH
* FR70 Rake Wheel RH
14. BFR652 10mm Lock Nut
15. T175 10mm x 25mm Carriage Bolt
16. FR73 Rake Wheel Tooth
17. FR74 Rake Tooth Clip
18. FR71 Rake Wheel Center
19. BFR657 Rake Wheel Hub
20. BFR438 5/8” x 2” Bolt GR. 5 (14 PCS.)
21. FR72 Rake Wheel Band
22. BFR635 Hose 1/2”FP x 1/2”MP x 33’
23. JB82 1/2” To 3/8” Bushing
24. BFR555 Adapter
25. T69 Lock Washer
26. T68 5/8” Nut
-29-
