FIGURE 7
1460-1660 HI-CAPACITY RAKE
OPTIONAL 2-WHEEL KICKER WHEEL
ITEM PART NO. DESCRIPTION
1. BFR369 Rake Wheel Ring
2. BFR370 Rake Wheel Center
3. T123 3/8” x 2-1/4” Bolt GR. 5
4. T82 Rake Wheel Tooth
5. K93 3/8” Lock Nut
6. BFR371 Rake Wheel Spacer
7. B68 3/8” Lock Washer
8. T173 Hub Cap
9. T172 Nut
10. T169 Cotter Pin
11. T168 10mm x 25mm Bolt
12. T166 10mm Nut
13. T170 Outer Bearing
14. T171 Outer Race
15. BFR32 Rake Wheel Hub
16. T165 Inner Race
17. T164 Inner Bearing
18. T163 Seal
19. BFR511 Center Kicker Wheel Arm
20. 18N48 3/4” x 3” Pivot Pin Bolt GR. 5
21. HE7 Lock Nut
22. BFR197 Locking Pin
23. ES7 Hair Pin
24. BFR369 Spindle
25. BFR374 3/8” x 3” I-Bolt
26. BFR512 Center Kicker Wheel Pivot
27. BR62 Spring
28. 9S17 1/2” Lock Nut
29. BFR375 1/2” x 2-1/2” Bolt GR. 5
30. BFR114 Piston
31. BFR115 O-Ring
32. BFR116 Hydraulic Cylinder
33. BFR74 3/8” Pipe Tee
34. BFR380 Orifice
35. BFR122 Union Adapter w/Orifice
36. BFR737 Hydraulic Hose 1/4” x 53” 3/8”MP x 1/4”MP
37. BFR379 Axle Shaft
38. 3G22 Roll Pin
39. BFR27 Bushing
40. BFR515 Cylinder Pin
41. T72 5/32” x 1-1/2” Cotter Pin
42. BFR514 Kicker Wheel Offset
43. BFR736 Stand Off
