FIGURE 8
1460-1660 HI-CAPACITY RAKE
OPTIONAL 3-WHEEL KICKER WHEEL
ITEM PART NO. DESCRIPTION
1. BFR717 Kicker Rake Beam
2. BFR718 Pivot
3. BFR719 Square Rake Arm
4. BFR514 Kicker Wheel Offset
5. BFR736 Standoff
6. BFR370 Rake Wheel Center
7. BFR369 Rake Wheel Ring
8. T82 Rake Wheel Tooth
9. T123 3/8” x 2-1/4” Bolt GR. 5
10. BFR371 Rake Wheel Spacer
11. B68 Lock Washer
12. K93 3/8” Lock Nut
13. T163 Seal
14. T164 Inner Bearing
15. T165 Inner Race
16. T168 10mm x 25mm Bolt
17. BFR32 Rake Wheel Hub
18. T166 10mm Nut
19. T171 Outer Race
20. T170 Outer Bearing
21. T172 Nut
22. T169 Cotter Pin
23. T173 Hub Cap
24. BFR721 Beam Lock Pin
25. X97 Hair Pin
26. BFR197 Locking Pin
27. ES7 Hair Pin
28. BFR720 Pivot Lock Collar
29. BFR23 3/4” x 4” Pivot Pin Bolt GR. 5
30. BFR722 Lift Cylinder Spacer
31. BFR374 3/8” x 3” I-Bolt
32. BR62 Spring
33. BFR515 Cylinder Pin
34. 3G22 Roll Pin
35. HE7 Lock Nut
36. 9S17 1/2” Lock Nut
37. BFR27 Bushing
38. LW131 1/2” x 3-1/2” Bolt GR. 5
39. BFR114 Piston
40. BFR115 O-Ring
41. BFR116 Hydraulic Cylinder
42. BFR737 Hydraulic Hose 1/4”x53” 3/8”MPx1/4”MP
43. BFR122 3/8” Union Adapter
44. BFR380 Orifice
45. BFR74 3/8” Pipe Tee
46. BFR379 Axle Shaft
