Section 3. Bolt on Tail
Rubber Bands (4 per side to hold wing)
Small Washers
Long Screws
Large Washers
Assembly Diagram
Please carefully read through the entire
instruction manual before beginning assembly
of the Arrow Semi-Symmetrical Trainer Ready-To-Fly (RTF) kit.
