HANKISON HPRP 75 User Manual

F
R
A
N
Ç
A
I
S
11 Fr
25 35 50
DESCRIPTION
115/1/60 208-230/1/60 220-240/1/50 115/1/60 208-230/1/60 220-240/1/50 115/1/60 208-230/1/60 220-240/1/50
DES PIÈCES
100/1/50
100/1/50 100/1/50
Groupe compresseur-
condenseur (refroidi par aire) 4130.120.7 4130.120.8 4130.120.9 4130.121.8 4130.121.9 4130.121.10 4130.122.10 4130.122.11 4130.122.15
Compresseur seulement 4130.108.34 4130.108.61 4130.108.35 4130.108.38 4130.108.39 4130.108.40 4130.108.41 4130.108.42 4130.108.43
Surcharge 5925.570.2 5925.578.24 5925.570.3 5925.578.1 5925.578.2 5925.578.3 5925.578.4 5925.578.5 5925.578.6
Relais de démarrage 5945.655.5 5945.683.24 5945.655.6 5945.683.1 5945.683.2 5945.683.3 5945.683.4 5945.683.5 5945.683.6
Condenseur de démarrage —— —— — ——5910.103.23 —
Moteur de ventilateur 6105.239.1 6105.237.4 6105.237.4 6105.238.27 6105.238.28 6105.238.28 6105.238.29 6105.238.30 6105.238.30
Pale de ventilateur 4140.228.2 4140.228.2 4140.228.2 4140.227.17 4140.227.17 4140.227.17 4140.227.18 4140.227.18 4140.227.18
Condenseur (refroidi par air) 4130.110.26 4130.110.26 4130.110.26 4130.111.18 4130.111.18 4130.111.18 4130.111.19 4130.111.19 4130.111.19
Séchoir 4130.165.14 4130.165.14 4130.165.14 4130.165.14 4130.165.14 4130.165.14 4130.165.14 4130.165.14 4130.165.14
Vanne de dérivation des gaz chauds 9802-1 9802-1 9802-1 9802-1 9802-1 9802-1 9802-1 9802-1 9802-1
Crépine de vanne de dérivation 4130.701.8 4130.701.8 4130.701.8 4130.701.8 4130.701.8 4130.701.8 4130.701.8 4130.701.8 4130.701.8
Ensemble de voyant, vert 6350.457.25 6350.457.23 6350.457.23 6350.457.25 6350.457.23 6350.457.23 6350.457.25 6350.457.23 6350.457.23
Indicateur de point de rosée 6685.283.1 6685.283.1 6685.283.1 6685.283.1 6685.283.1 6685.283.1 6685.283.1 6685.283.1 6685.283.1
Interrupteur marche-arrêt 6110.706.13 6110.706.13 6110.706.13 6110.706.13 6110.706.13 6110.706.13 6110.706.13 6110.706.13 6110.706.13
Trousse d’entretien HPRMK2 HPRMK2 HPRMK2 HPRMK2 HPRMK2 HPRMK2 HPRMK3 HPRMK3 HPRMK3
l’élément E9-16 E9-16 E9-16 E9-16 E9-16 E9-16 E9-20 E9-20 E9-20
Tuyau d’évacuation 4460.151.10 4460.151.10 4460.151.10 4460.151.10 4460.151.10 4460.151.10 4460.151.10 4460.151.10 4460.151.10
75 100 & 125 150
DESCRIPTION
115/1/60 208-230/1/60 220-240/1/50 115/1/60 208-230/1/60 220-240/1/50 115/1/60 208-230/1/60 220-240/1/50
DES PIÈCES
100/1/50 100/1/50 100/1/50
Groupe compresseur-
condenseur (refroidi par aire) 4130.122.12 4130.122.13 4130.122.14 4130.123.12 4130.123.13 4130.123.14 4130.134.31 4130.134.32 4130.134.33
Compresseur seulement 4130.108.44 4130.108.45 4130.108.46 4130.108.47 4130.108.48 4130.108.49 4130.108.50 4130.108.51 4130.108.52
Surcharge 5925.578.7 5925.578.8 5925.578.9 5925.578.10 5925.578.11 5925.578.12 5925.578.13 5925.578.14 5925.578.15
Relais de démarrage 5945.683.7 5945.683.8 5945.683.9 5945.683.10 5945.683.11 5945.683.12 5945.683.13 5945.683.14 5945.683.1
Condenseur de démarrage — 5910.103.26 5910.103.27 5910.103.28 5910.103.29 5910.103.29 5910.103.37 5910.103.38 5910.103.39
Moteur de ventilateur 6105.238.31 6105.238.32 6105.238.32 6105.238.33 6105.238.34 6105.238.34 6105.238.35 6105.238.36 6105.238.36
Pale de ventilateur 4140.227.19 4140.227.25 4140.227.25 4140.227.20 4140.227.20 4140.227.20 4140.227.21 4140.227.21 4140.227.21
Condenseur (refroidi par air) 4130.111.20 4130.111.20 4130.111.20 4130.111.21 4130.111.21 4130.111.21 4130.111.22 4130.111.22 4130.111.22
Séchoir4130.165.14 4130.165.14 4130.165.14 4130.165.14 4130.165.14 4130.165.14 4130.165.12 4130.165.12 4130.165.12
Manostat de ventilateur — ——— ——4130.138.13 4130.138.13 4130.138.13
Vanne de dérivation des gaz chauds 9802-1 9802-1 9802-1 9802-1 9802-1 9802-1 9802-1 9802-1 9802-1
Crépine de vanne de dérivation 4130.701.8 4130.701.8 4130.701.8 4130.701.8 4130.701.8 4130.701.8 4130.701.8 4130.701.8 4130.701.8
Ensemble de voyant, vert 6350.457.25 6350.457.23 6350.457.23 6350.457.25 6350.457.23 6350.457.23 6350.457.25 6350.457.23 6350.457.23
Indicateur de point de rosée 6685.283.1 6685.283.1 6685.283.1 6685.283.1 6685.283.1 6685.283.1 6685.283.1 6685.283.1 6685.283.1
Interrupteur marche-arrêt 6110.706.13 6110.706.13 6110.706.13 6110.706.13 6110.706.13 6110.706.13 6110.706.13 6110.706.13 6110.706.13
Condenseur (refroidi par eau) ————— —4130.134.34 4130.134.35 4130.134.36
Règulateur de dèbit d’eau ————— —4130.145.22 4130.145.22 4130.145.22
Crèpine ————— —4731.735.1 4731.735.1 4731.735.1
Filtre, Crèpine ————— —4731.735.5 4731.735.5 4731.735.5
Contacteur ————— —5910.134.11 ——
Trousse d’entretien HPRMK4 HPRMK4 HPRMK4 * * * HPRMK5 HPRMK5 HPRMK5
l’élément E9-24 E9-24 E9-24 ** ** ** E9-29 E9-28 E9-28
Tuyau d’évacuation 4460.151.10 4460.151.10 4460.151.10 4460.151.10 4460.151.10 4460.151.10 4460.151.10 4460.151.10 4460.151.10
Liste des pièces
*Modèle 100 - HPRMK4
Modèle 125 - HPRMK5
** Modèle 100 - E9-24
Modèle 125 - E9-28
