Hanna Instruments HI 8711 User Manual

27
FUNCTIONAL DESCRIPTION HI 932500
ORP CONTROLLER
Keypad
SET To set the working point of ORP
dosage
MEASURE To set HI 932500 on measure-
ment mode
Trimmers
SLOPE For Slope calibration
SET/COARSE To coarsely adjust the ORP
set point
SET/FINE To finely adjust the ORP set
point
Leds
OXID To show the oxidant dosage is
active
REDUC To show the reductant dosage
is active
FRONT PANEL
HI 932500
ORP Process
Controller
DOSAGE
SLOPE
OXID.
mV
REDUC.
SET
FINE
COARSE
MEA
SURE
SET
