11
Range 0.00 to 9.99 FTU
10.0 to 99.9 FTU
100 to 1000 FTU
Range Selection Automatically
Resolution 0.01 FTU from 0.00 to 9.99 FTU
0.1 FTU from 10.0 to 99.9 FTU
1 FTU from 100 to 1000 FTU
Accuracy ±2% of reading plus 0.1 FTU
Repeatibility ±1% of reading or 0.01 FTU, whichever is greater
Stray Light < 0.1 FTU
Typical EMC Deviation ±0.05 FTU
Light Source 860 nm infrared LED
IR Detector Silicon Photocell
Method Adaptation of ISO 7027, ratio method with 90° and 180° detector.
Display 60 x 90 mm LCD with backlight
Standards < 0.1, 15, 100 and 750 FTU
Calibration Two, three or four point calibration
LOG Memory 200 records
Serial Interface RS232 and USB 1.1
Environment 0 to 50°C (32 to 122°F); max 95% RH non-condensing
Power supply 4 x 1.5V AA alkaline batteries or AC adapter
Auto Shut-off After 15 minutes of non-use
Dimensions 224 x 87 x 77 mm (8.8 x 3.4 x 3.0”)
Weight 512 g (18 oz.)
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONSSPECIFICATIONS
SPECIFICATIONS
